Instrumentation Calculations and Analyses

InstruCalc 10

InstruCalc v10 stands out as the industry's most comprehensive and widely acclaimed desktop software, specializing in instrumentation calculations and analysis. This engineering software suite, known as InstruCalc, excels at determining essential engineering data and equipment requirements.


InstruCalc 10 calculates the dimensions of:

Control Valves

Flow Elements

Relief Devices

Fluid Properties

Pipe Pressure Loss

Liquid Water Hammer

Comprised of over 74 programs divided into four main sections, as detailed on the following pages, this software utilizes InstruCalc to size over 50 different instruments. This user-friendly and precise sizing program calculates the dimensions of control valves, flow elements, and relief devices, as well as generating data sheets for the specified paramete

Instrumentation Calculations and Analyses
Instrumentation Calculations and Analyses

Control Valve Sizing Programs

For liquid, gas, steam, and two-phase flow using the ISA formulas.


Flow Element Sizing Programs

Calculations for flow meters such as Integral Flow Orifice Assembly, Annubar Pitot tubes, Vortex Flowmeters, Rotameters and Target meters for gas or liquid.


Process (Engineering) Data Calculations

Is a set of programs that determines line pressure drops for gas and liquids, a water hammer program for determining closing times for valves in long liquid filled lines, and process data programs for liquid and gas that will provide process data from the data bank at the pressure and temperature entered.


Relief Devices for pressure-relief devices

Rupture discs, and breather valves. Liquid and gas application.


Calculates API or ASME size for known flow

Thermal expansion, and external fire. The external fire program has the option of either the API or the NFPA heat input methods.
